Huawei S1720 User Manual

S1700 Managed Series Ethernet Switches
Web User Manual
9 Security
Issue 05 (2012-10-25)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
173
9.14.5 RADIUS Statistic
Click Security > RADIUS > RADIUS Statistic to display the RADIUS Statistic on switch, the
configuration page is displayed as follows.
Figure 9-63 RADIUS Statistic
Table 9-43 Parameters of RADIUS Statistic
Item
Description
RADIU-server
Authentication/Accounting
Address
The RADIUS server IP address to be
authenticated/accounted.
Auth-port
The authentication port number of RADIUS server.
Acct-port
The accounting port number of RADIUS severs.
Parameter
Round Trip Time, Access Requests, Access Rejects,
Access Challenges, Acct Request, Acct Response,
Retransmissions, Malformed Response, Bad
Authenticators, Pending Requests, Timeouts, Unknown
Types, Packets Dropped.
9.15 SSL Settings
Secure Sockets Layer (SSL) uses authentication, digital signature and encryption to provide
secure communication between the host and client.
When the SSL feature is enabled, Web becomes disabled. To manage the switch through Web,
Web browser must support SSL encryption, and URL must begin with "https://" (for example
https:/192.168.1.253).
Click Security > SSL Settings to enable the SSL function on switch, the configuration page is
displayed as follows.
Figure 9-64 SSL Settings

Huawei S1720 Specifications

General

Operating Temperature	0°C to 45°C
MAC Address Table	8K
Ports	4 100/1000BASE-X SFP ports
VLAN	4094
Stacking	Not supported
Dimensions	442 mm x 220 mm x 43.6 mm (S1720-28GFR-4P)
Power Supply	AC: 100 V to 240 V, 50/60 Hz
Series	S1700
Type	Fixed
Fixed ports	4 x GE Combo
Storage Temperature	-40°C to +70°C
Operating Humidity	5% to 95% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
