Huawei S1720 User Manual

S1700 Managed Series Ethernet Switches
Web User Manual
3 System Management
S1700 Managed Serie s Etherne t Switches
Issue 05 (2012-10-25)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
15
Item
Description
Upload File
Upload the chosen files to local computer.
Delete
Delete the chosen files from switch.
CAUTION
Those specified as startup files can not be deleted.
Delete System Files of Switch
Step 1 Click System Management > File Management, the webpage as shown in Fig.3-4 appears.
Step 2 Choose system files to be deleted from list.
Step 3 Click Delete button.
----End
3.5 System Configuration
Click System Management > System Configuration, to set device name and HTTP connection
timeout duration of switch, the configuration page is as shown in Fig.3-5.
Figure 3-5 System Configuration
Table 3-5 Parameters of System Configuration
Item
Description
Device Name
Enter the device name of switch with a maximal length of 255
characters.
HTTP Connection
Timeout Duration
Enter the HTTP connection timeout duration of switch within
1-35791 minutes, default is 3 minutes.

Huawei S1720 Specifications

General

Operating Temperature	0°C to 45°C
MAC Address Table	8K
Ports	4 100/1000BASE-X SFP ports
VLAN	4094
Stacking	Not supported
Dimensions	442 mm x 220 mm x 43.6 mm (S1720-28GFR-4P)
Power Supply	AC: 100 V to 240 V, 50/60 Hz
Series	S1700
Type	Fixed
Fixed ports	4 x GE Combo
Storage Temperature	-40°C to +70°C
Operating Humidity	5% to 95% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
