Huawei S1720 User Manual

S1700 Managed Series Ethernet Switches
Web User Manual
9 Security
Issue 05 (2012-10-25)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
141
Table 9-16 Parameters of Port Security Address Information
Item
Description
Query
Query security address information of interface specified in Interface
Name.
Interface Name
Interface Number.
VLAN
Bound VLAN number
MAC Address
Bound MAC address.
Type
Bound type of MAC address.
Remaining Time
The “-” displayed in Remaining Time field is based on the following
three conditions:
Firstly, the aging time is not configured; secondly, the aging time is
configured and the type of aging time is absolute; thirdly, the aging
time is configured and the type of aging time is inactivity and there is
traffic of the security address. If the aging time is not configured, the
security address will never be automatically deleted.
Create a Security Address Entry
Step 1 Click Security> Port Security.
Step 2 Click Security Address Information in Tab.
Step 3 Click New button to add new security address information entry, the configuration page is
displayed as follows.
Figure 9-23 New Security Address Information.
Table 9-17 Parameters of New Security Address Information
Item
Description
Interface Name
Select the interface number which needs to be bound.

Huawei S1720 Specifications

General

Operating Temperature	0°C to 45°C
MAC Address Table	8K
Ports	4 100/1000BASE-X SFP ports
VLAN	4094
Stacking	Not supported
Dimensions	442 mm x 220 mm x 43.6 mm (S1720-28GFR-4P)
Power Supply	AC: 100 V to 240 V, 50/60 Hz
Series	S1700
Type	Fixed
Fixed ports	4 x GE Combo
Storage Temperature	-40°C to +70°C
Operating Humidity	5% to 95% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
