Huawei SmartAX MA5600T Hardware Description

Position Description
3.2 Mapping Between
Boards and Software
Versions
Modified the mapping between some boards and versions.
Appearance of subracks Deleted the notes below the figures of subrack
appearance.
Updates in Issue 03 (2013-07-25)
Based on issue 02 (2013-04-30), the document is updated as follows:
Included the V800R013C00SPC100 updates.
Position
Description
Appearance of cabinets Added appearance description of cabinets.
Parameters of subracks and
chassises
Modified the power consumption of service subracks and
chassises.
Work temperature of boards Added the description of work temperature of boards.
3.23.2 H806VPEA Board
Description
Added the power consumption of H806VPEA board.
3.2 Mapping Between
Boards and Software
Versions
Modified the mapping between some boards and versions.
3 Board
l Optimize the comparison of similar boards. Some
software specifications are added.
l Optimize the board description. The figures of external
connections and internal principle are combined as one
figure.
Updates in Issue 02 (2013-04-30)
Based on issue 01 (2013-03-15), the document is updated as follows:
Position
Description
3 Board Added the boards: 3.15.9 H801GPMD Board
Description, 3.7.4 H801MCUE Board Description,
3.11.2 H801MPWD Board Description, 3.6.10
H801SCUV Board Description, 3.12.5 H801SPUF
Board Description, 3.23.2 H806VPEA Board
Description.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
About This Document
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
x

Huawei SmartAX MA5600T Specifications

General

Brand	Huawei
Model	SmartAX MA5600T
Category	Control Unit
Language	English
