Board Type Board Appearance Dimensions (W x D x H)
SPL board 22.86 mm x 237.00 mm x 395.40 mm
3.1.3 Board Name and Version
This topic describes the board name and version.
As shown in Figure 3-3 (using the SCUN board as an example), the board name and version
are printed on the PCB of a board.
Figure 3-3 Board name and version
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
147
