Page #384 background imageLoading...
Page #384 background image
Indicators
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Red Blinking The board enters the phase
of communication with the
control board during its
startup
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board enters the APP
start phase during the
board startup
Green Blinking slowly (on
for 1 s and off for 1 s
repeatedly)
The board works in the
normal state
Orange Blinking A high-temperature alarm
is generated
Red On The board is faulty
BSY Port status
indicator
Green Blinking At least one service port is
activated
- Off No service port is activated
3.14.3 H801CSPA Board Description
The H801CSPA is a CESoP service processing board. It supports the structure-agnostic TDM
over packet (SAToP) processing of 64 channels of E1 signals.
Functional Specifications
The H801CSPA board supports the following functions:
l SAToP processing of 64 channels of E1 signals
l 8 kHz clock channel from the H801CSPA board to the backplane, which is used to
transmit the clock signals recovered from the service to the control board
l Automatic power shutdown in case of a high temperature
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
364
