Jump
er
Pin End of E1 Channel Jump
er
Pin End of E1 Channel
11-12 Rx end of the 7th E1
channel
11-12 Rx end of the 15th E1
channel
13-14 Tx end of the 8th E1
channel
13-14 Tx end of the 16th E1
channel
15-16 Rx end of the 8th E1
channel
15-16 Rx end of the 16th E1
channel
Table 3-80 describes the software query (a reserved function) supported by jumper J11 and
J21.
Table 3-80 Software query (a reserved function) supported through jumpers J11 and J21
Jumper
Contents Queried Through the
Software
J11 Whether the shield layer of the E1 transmit
end is grounded
J21 Whether the shield layer of the E1 receive
end is grounded
3.20.11 H80AATRB Board Description
H80AATRB is a 32-channel foreign exchange office (FXO) service board, providing direct
access services.
Functional Specifications
Specification
Supported or Not
Ringing detection Yes
Overcurrent protection Yes
CID Yes
G.711A/u Yes
Pulse dialing Yes
DTMF dialing Yes
Configurable port impedance Yes
Hookflash function Yes
ITU K.20; K.45 Yes
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
515
