Huawei SmartAX MA5600T Hardware Description

Jumper Setting Indication Default
Setting
J11 and J21 Connected The shield layer of the E1 cable is
grounded.
Connected
Disconnected The shield layer of the E1 cable is not
grounded.
Table 3-79 describes the mapping between jumpers J15, J16, J17, J18, and the E1 port.
Table 3-79 Mapping between jumpers J15, J16, J17, J18, and the E1 port
Jump
er
Pin End of E1 Channel Jump
er
Pin End of E1 Channel
J15 1-2 Tx end of the first E1
channel
J17 1-2 Tx end of the 9th E1
channel
3-4 Rx end of the first E1
channel
3-4 Rx end of the 9th E1
channel
5-6 Tx end of the 2nd E1
channel
5-6 Tx end of the 10th E1
channel
7-8 Rx end of the 2nd E1
channel
7-8 Rx end of the 10th E1
channel
9-10 Tx end of the 3rd E1
channel
9-10 Tx end of the 11th E1
channel
11-12 Rx end of the 3rd E1
channel
11-12 Rx end of the 11th E1
channel
13-14 Tx end of the 4th E1
channel
13-14 Tx end of the 12th E1
channel
15-16 Rx end of the 4th E1
channel
15-16 Rx end of the 12th E1
channel
J16 1-2 Tx end of the 5th E1
channel
J18 1-2 Tx end of the 13th E1
channel
3-4 Rx end of the 5th E1
channel
3-4 Rx end of the 13th E1
channel
5-6 Tx end of the 6th E1
channel
5-6 Tx end of the 14th E1
channel
7-8 Rx end of the 6th E1
channel
7-8 Rx end of the 14th E1
channel
9-10 Tx end of the 7th E1
channel
9-10 Tx end of the 15th E1
channel
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
514
