Cable Connector
Technical Specifications
Table 5-3 lists the technical specifications of an AC power cable.
NOTE
Specifications of the AC power cable vary with country/area. The following uses the AC power cable
that meets the Chinese standard as an example.
Table 5-3 Specifications of an AC power cable
Specification
Description
Connector 1 PI straight male
Connector 2 C13 straight female
Cable type External power cable
Cable length 1.8 m
Cross-sectional area of the conductor
1.0 mm
2
5.1.5 PGND Cable (Cabinet)
PGND cable (cabinet) is used for protect cabinet from lightning strike and interference.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
5 Cable
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
867
