Huawei SmartAX MA5600T Hardware Description

Table 2-37 Settings of S1-5 and S1-6
S1-6 S1-5 Fan Quantity
ON ON 6
ON OFF 8
OFF ON 4
OFF OFF 10
Table 2-38 Settings of S1-7 and S1-8
S1-8
S1-7 Speed Adjustment Mode Adjustment Strategy
ON ON Temperature measurement at
the air intake vent (reserved)
Strategy 1
ON OFF Temperature measurement at
the air exhaust vent
Strategy 2
OFF ON Temperature measurement at
the air intake vent
Strategy 3
OFF OFF Temperature measurement at
the air intake vent (the fan stops
rotating)
Strategy 4
NOTE
The fan tray (FMCA) of the MA5603T must use speed adjustment policy 1.
Fan Speed Adjustment
Set the fan speed adjustment mode to "automatic" or "manual" in the command line interface
(CLI). After the fans are installed, they work in automatic mode by default.
l Automatic mode
– Control-system-triggering: The control system automatically adjusts fan speed
according to the board temperatures for energy conservation.
– Monitoring-board-triggering: The speed is automatically adjusted based on the
temperature which is detected by a temperature sensor.
NOTE
The automatic mode has two variants (automatically selected by the system): control-system-
triggering and monitoring-board-triggering.
l Manual mode
Commands are executed to adjust fan speed. The levels range from 0 to 6, level 0 being
the lowest speed and level 6 being the highest speed.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
2 Subrack and Chassis
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
123
