Huawei SmartAX MA5600T Hardware Description

Board Power Consumption Maximum Frame Size
H802VDNF
l 17a:
– Static: 35 W
– Maximum: 90 W
l 8b:
– Static: 35.2 W
– Maximum: 96 W
l PTM: 1536 bytes
l ATM: 1800 bytes
H802VDJM
l 17a:
– Static: 33 W
– Maximum: 82 W
l 8b:
– Static: 33 W
– Maximum: 99 W
l PTM: 1536 bytes
l ATM: 1800 bytes
H80AVDPD
l 17a:
– Static: 24 W
– Maximum: 77 W
l 8b:
– Static: 24 W
– Maximum: 89 W
l PTM: 1518 bytes
l ATM: 1800 bytes
H80BVDPE
l 17a:
– Static: 24 W
– Maximum: 79 W
l 8b:
– Static: 24 W
– Maximum: 86 W
l PTM: 2000 bytes
l ATM: 1800 bytes
H80BVDPM
l 17a:
– Static: 25 W
– Maximum: 82 W
l 8b:
– Static: 25 W
– Maximum: 89 W
l PTM: 2000 bytes
l ATM: 1800 bytes
H80BVDQM
l 17a:
– Static: 24 W
– Maximum: 81 W
l 8b:
– Static: 24 W
– Maximum: 82 W
l PTM: 2000 bytes
l ATM: 1800 bytes
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
179
