Huawei SmartAX MA5600T Hardware Description

Table 3-8 Ports of SCU boards
Board Panel
ports
Internal interfaces
Channel
to the
service
board
Channel to the GIU
board
Channel to the
standby
control board
Note
H801S
CUB/
H802S
CUB
4 GE
ports
16 GE
channels
l Providing four GE
ports for upstream
transmission using
the control board or
upstream board,
which is controlled
by the electronic
switch.
l Providing four GE
ports for upstream
transmission using
the upstream board.
Either the last GE
port or VoIP daughter
board can be used for
upstream
transmission, which
is controlled by the
electronic switch.
- -
H801S
CUF
4 GE
ports
16 GE
channels
Provides four GE
channels and one 10GE
channel for each
upstream slot
- Reserves
two
10GE
channels
(not
available
currently
) for the
MPLS
daughter
board.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
199
