NOTE
l The filled holes are for floating nuts to fasten subracks.
l For the I-type or C3-type PDU, use installation holes 79 and 82; for the B-type PDU, use installation
holes 79 and 81.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
1 Cabinet
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
