Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Red Blinking The board enters the APP
start phase during the
board startup
Green Blinking slowly (on
for 1 s and off for 1 s
repeatedly)
The board functions
properly
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board is starting up
Red On The board is faulty
ACT Active/
standby
status
indicator
Green On The ACT indicator has no
significant indication until
it is assigned
LINK Link status
indicator
Green On A connection is set up on
the port
- Off No connection is set up on
the port
ACT Data status
indicator
Yellow Blinking Data is being transmitted
- Off No data is being
transmitted
Daughter Board
The H801ETHA board provides two slots for daughter boards. Figure 3-55 shows the
positions of daughter boards on the H801ETHA board.
