Indicato
r
Name Color Status Meaning
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board enters the APP
start phase during the
board startup
Green Blinking slowly (on
for 1 s and off for 1 s
repeatedly)
The board works in the
normal state
Orange Blinking A high-temperature alarm
is generated
Red On The board is faulty
BSY Port status
indicator
Green On
(supported in
V800R012C00 and
earlier versions)
At least one service port is
activated
Green Blinking
(supported in
V800R013C00 and
earlier versions)
At least one service port is
activated
- Off No service port is activated
Pin Assignments of the NH1A Daughter Board
Table 3-33 describes the pin assignments of the E1 port on the front panel of the H801TOPA
board.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
357
