Specification H801OPFA H802OPGD H802OPGE
Optical Module eSFF FE CSFP (48-channel) or
SFP (24-channel) GE/FE
CSFP (48-channel) or
SFP (24-channel) GE/FE
Limit on the
Traffic
Classification
Parameters
N/A
l The user VLAN ID
ranges from 1 to
4093, but cannot be
set to 4094 or 4095.
l The user VLAN
packets cannot be
priority-tagged.
l The user VLAN ID
ranges from 1 to
4093, but cannot be
set to 4094 or 4095.
l The user VLAN
packets cannot be
priority-tagged.
Cascading and
aggregation of
DSLAMs or
MDUs
No Yes
NOTE
You can run the network-
role command in the opg
mode to switch the board
role. Default board role is
user.
Yes
NOTE
You can run the network-
role command in the opg
mode to switch the board
role. Default board role is
user.
Synchronous
Ethernet clock
issuing
Yes
NOTE
The
H801OPFA
board only
issues
synchronous
Ethernet clock
signals (line
recovered
clock signals
using the
interface
board), which
cannot be used
as the system
clock source.
Yes Yes
1588v2 clock
issuing
No No Yes
Inter-board
aggregation and
load sharing
No Yes Yes
9216-byte jumbo
frames
No No Yes
Temperature
query
Yes Yes Yes
Automatic
power shutdown
in case of a high
temperature
No Yes Yes
