ATM/PTM packets into IP packets and performs CAR on the IP packets. The IP packets
are transmitted to the backplane bus through the backplane port and then to the control
board. After being processed by the control board, the IP packets are transmitted
upstream to the upper level device through the optical or electrical port.
l In the downstream direction, the forwarding logical decapsulates the IP packets from the
Ethernet, performs CAR on the IP packets, reorganizes the IP packets into ATM/PTM
packets, and transmits the ATM/PTM packets to the interface module. The interface
module converts the ATM/PTM packets into analog signals and transmits the signals to
subscriber lines.
Port
Table 3-111 Port of the H805VDSF board
Port
Function Connection
xDSL Supports 0-23 channels of VDSL2
services.
Use the 5.2.4 32-Channel Inter-
Subrack Interconnection Cable
(for 32/24-Channel Board) or
5.2.1 32-Channel Intra-Subrack
Interconnection Cable (for
32/24-Channel Board) to
connect the port to the xDSL port
of the SPL board, or use the
VDSL subscriber cable to
connect the port to the MDF.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
612
