NOTICE
l When cables from the xDSL ports are routed to an outdoor environment or the user side,
the MDF must be installed with a protective unit.
Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Red Blinking The board is in the APP
startup phase
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board is
communicating with the
control board
Green Blinking slowly (on
for 1 s and off for 1 s
repeatedly)
The board works in the
normal state
Red On The board is faulty
BSY Port status
indicator
Green On At least one service port is
activated
- Off No service port is activated
Pin Assignments
Table 3-114 describes the pin assignments of the xDSL port on the front panel of the
H805VDRD board.
