NOTICE
The device supports protection specification 1500 V (the basic standard is ITU-T K.20). If the
device is placed in the scenario where the supported protection specification is higher than
1500 V, a protective unit needs to be configured on the MDF.
Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Green Blinking slowly (on
for 1 s and off for 1 s
repeatedly)
The board works in the
normal state
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board is starting up
Orange Blinking A high-temperature alarm
is generated
Red On The board is faulty
BSY Port status
indicator
Green On At least one service port is
activated
- Off No service port is
activated
Pin Assignments
Table 3-143 describes the pin assignments of the xDSL0 port on the front panel of the
H80DVCPM board, and Table 3-144 describes the pin assignments of the xDSL1 port on the
front panel of the H80DVCPM board.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
705
