One-channel Two-fiber Bi-directional GE CWDM Optical Module
A GE CWDM optical module is connected to two LC optical fibers (one for transmission and
the other for reception) to provide one GE channel.
Type One-channel two-fiber bi-directional optical module
Operating
Wavelength
1471 nm, 1491 nm, 1511 nm, 1531 nm, 1551 nm, 1571 nm, 1591 nm,
1611 nm
Encapsulation
Type
eSFP
Port Rate 100 Mbit/s-2.67 Gbit/s
Minimum
Output Optical
Power
0 dBm
Maximum
Output Optical
Power
5.0 dBm
Maximum
Receiver
Sensitivity
-28.0 dBm
Optical
Connector Type
LC
Optical Fiber
Type
Single-mode
Reach 80.0 km
Overload Optical
Power
-9.0 dBm
Extinction Ratio 8.5 dB
NOTE
There are different types of GE CWDM optical modules, and these types of optical modules vary with
the operating wavelength.
GE Electrical Module
A GE electrical module is connected to a network cable to provide one GE channel.
Type
1000Base-T RJ45 electrical port
Encapsulation
Type
SFP
Port Rate Full-duplex 1000 Mbit/s
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
