Huawei SmartAX MA5600T Hardware Description

Optical
Connector
Type
LC LC LC LC LC LC
Optical Fiber
Type
Single-mode Single-mode Single-mode Single-mode Single-mode Single-mode
Reach 20km 20km 10km 10km 40km 40km
Overload
Optical
Power
0.5dBm 0.5dBm 0.5dBm 0.5dBm -9dBm -9dBm
Extinction
Ratio
3.5dB 3.5dB 3.5dB 3.5dB 3.5dB 3.5dB
One-channel Two-fiber Bi-directional 10GE CWDM Optical Module
A 10GE CWDM optical module is connected to two LC optical fibers (one for transmission
and the other for reception) to provide one 10GE channel.
Type One-channel two-fiber bi-directional optical module
Operating
Wavelength
1471 nm, 1491 nm, 1511 nm, 1531 nm, 1551 nm, 1571 nm, 1591 nm,
1611 nm
Encapsulation
Type
SFP+
Port Rate 9.95 Gbit/s-11.1 Gbit/s
Minimum
Output Optical
Power
0 dBm
Maximum
Output Optical
Power
4.0 dBm
Maximum
Receiver
Sensitivity
-23.0 dBm
Optical
Connector Type
LC
Optical Fiber
Type
Single-mode
Reach 70.0 km
Overload Optical
Power
-7.0 dBm
Extinction Ratio 8.2 dB
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
857
