Position Description
3 Board Added the boards: 3.15.6 H807GPBH Board
Description, 3.15.8 H805GPFD Board Description,
3.19.6 H806CCPE Board Description, 3.22.16
H806VCPE Board Description, 3.23.4 H806VPGA
Board Description, 3.16.3 H801XGBD Board
Description.
4 Optical and Electrical
Module
Added the 4.6 FE/GE Adaptive Optical Module.
Added an one-channel one-fiber bi-directional FE optical
module in 4.5 FE Optical Module.
3.3 Power Consumption and
Maximum Frame Size of
Boards
The power consumption and maximum frame size of
boards are all introduced in 3.3 Power Consumption and
Maximum Frame Size of Boards. Parameter MTU is
modified to Maximum Frame Size. Parameter Maximum
Frame Size indicates the maximum frame transmission
capability of a board.
3.6 Control Board (SCU)
3.7 Control Board (MCU)
Optimized the LED status description of control boards.
3.21 ADSL2+ Service Board
3.22 VDSL2 Service Board
3.24 SHDSL Service Board
Added the DC block in the working principle figures of
xDSL boards.
Included the V800R015C00 updates.
Updates in Issue 08 (2013-12-18)
Based on issue 07 (2013-11-15), the document is updated as follows:
Position
Description
3.5 Board
Configuration(MA5608T)
Added the H802GPBD, H805VDRD boards in 3.5 Board
Configuration(MA5608T).
3.2 Mapping Between
Boards and Software
Versions
The Out of Production information is replaced by Life
Cycle Status information in 3.2 Mapping Between
Boards and Software Versions. The out of production
information in the board description is deleted. Please
query the information in 3.2 Mapping Between Boards
and Software Versions.
Updates in Issue 07 (2013-11-15)
Based on issue 06 (2013-10-30), the document is updated as follows:
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
About This Document
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
viii
