Huawei SmartAX MA5600T Hardware Description

Figure 5-6 Pin assignments of the 64-channel subscriber cable (DOWN)
X2 LINE/PSTN Label X2 LINE/PSTN Label
16 White 48 White
15 Blue 47 Blue
14 White 46 White
13
Orange
45
Orange
12 White 44 White
11 Green 43 Green
10 White 42 White
9 Brown 41 Brown
8 White 40 White
7 Grey 39 Grey
6 Red 38 Red
5 Blue 37 Blue
4 Red 36 Red
3
Orange
35
Orange
2 Red 34 Red
1 Green 33 Green
X2 LINE/PSTN Label X2 LINE/PSTN Label
32 Red 64 Red
31 Brown 63 Brown
30 Red 62 Red
29 Grey 61 Grey
28 Black 60 Black
27 Blue 59 Blue
26 Black 58 Black
25
Orange
57
Orange
24 Black 56 Black
23 Green 55 Green
22 Black 54 Black
21 Brown 53 Brown
20 Black 52 Black
19 Grey 51 Grey
18 Yellow 50 Yellow
17 Blue 49 Blue
Color
Color
Blue
bundle
0
DOWN
Orange
bundle
1
2
3
4
16
DOWN
17
18
19
20
21
22
23
Blue
bundle
8
DOWN
Orange
bundle
9
DOWN
25
10
26
11
27
12
28
13
29
14
30
24
5
6
7
Color
Color
15
31
Specification
Specification
Description
Connector Delander 64-pin
Type Symmetrical twisted pair
Color PANTONE 430 U (PANTONE refers to
international standard color cards and
430 U is close to grey)
Characteristic impedance 100.0 ohms
Wire diameter of the inner conductor 0.40 mm (26 AWG)
Wire 128-wire
Breakdown voltage 1000.0 V
DC resistance of the inner conductor 145.0 ohms/km
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
5 Cable
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
888
