Huawei SUN2000-8KTL-M1 User Manual

Parameters Settings
On the home screen, choose Power adjustment > Battery control, and set the
battery parameters and working mode.
Figure 7-14 Battery control parameter setting
Parameter Description Value Range
Working mode For details, see the description
on the App screen.
● Maximum self-
consumption
● Time-of-use
● Fully fed to grid
Maximum charge
power (kW)
Retain this parameter to the
maximum charge power.
Additional conguration is not
required.
● Charge: [0,
Maximum charge
power]
Maximum discharge
power (kW)
Retain this parameter to the
maximum discharge power.
Additional conguration is not
required.
● Discharge: [0,
Maximum
discharge power]
End-of-charge SOC
(%)
Set the charge cuto capacity. 90%–100%
End-of-discharge
SOC (%)
Set the discharge cuto
capacity.
0%–20% (When no PV
module is congured
or the PV modules
have no voltage for 24
hours, the minimum
value is 15%.)
SUN2000-(3KTL-10KTL)-M1 Series
User Manual 7 Man-Machine Interaction
Issue 17 (2024-01-12) Copyright © Huawei Technologies Co., Ltd. 95

Huawei SUN2000-8KTL-M1 Specifications

General

Max. Efficiency	98.6%
Max. Input Voltage	1100 V
Nominal Input Voltage	600 V
Number of MPP Trackers	2
Max. Output Power	8000 W
Nominal Output Frequency	50 Hz / 60 Hz
Weight	17 kg
Max. apparent AC power	8800 VA
Rated AC power	8000 W
Operating Temperature Range	-25°C to +60°C
Cooling	Natural Convection
Protection Degree	IP65
Warranty	10 years
Nominal Output Voltage	230 V / 400 V
