Huawei SUN2000 M0 Series User Manual

F IPS Test (for Italy CEI0-21 Grid Code
only)
Prerequisites
You have logged in to the app as installer. The initial password is 00000a. Use the
initial password upon rst power-on and change it immediately after login. To
ensure account security, change the password periodically and keep the new
password in mind. Not changing the initial password may cause password
disclosure. A password left unchanged for a long period of time may be stolen or
cracked. If a password is lost, devices cannot be accessed. In these cases, the user
is liable for any loss caused to the PV plant.
Context
The Italy CEI0-21 grid code requires an IPS test for the SUN2000. During the IPS
test process, the SUN2000 consecutively tests the protection thresholds and time
for 10-min overvoltage, level 1 overvoltage, level 1 undervoltage, level 1
overfrequency, and level 1 underfrequency. The SUN2000 shuts down after the IPS
test starts, and it restarts after the IPS test is successful.
Procedure
Step 1 On the Home screen, choose Device maintenance > IPS test to access the IPS
test screen.
SUN2000-(3KTL-10KTL)-M0
User Manual F IPS Test (for Italy CEI0-21 Grid Code only)
Issue 06 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 103

Huawei SUN2000 M0 Series Specifications

General

Rated AC Output Power	3000W
European Efficiency	96.7%/97%/97%/97.3%/97.5%/97.8%
Communication	RS485, Wi-Fi
Protection Degree	IP65
Weight	17 kg
Dimensions	440 x 650 x 220 mm
Max. efficiency	98.6%
MPPT voltage range	200-1000V
No. of MPPTs	2
Operating temperature range	-25°C to +60°C
Cooling method	Natural convection
Protection rating	IP65
AC output voltage	230V
