Huawei SUN2000 M0 Series User Manual

No. Name Type Recommended
Specications
3 (Optional) RS485
communications cable
(used to connect to
the RS485 signal port
on devices such as the
Smart Power Sensor
and the energy
storage device)
Two-core outdoor
shielded twisted pair
cable
● Conductor cross-
sectional area: 0.2–
1 mm
2
Note: When
devices such as the
Smart Power
Sensor and the
energy storage
device are both
connected to the
inverter, use 0.2–
0.5 mm
2
cords.
● Cable outer
diameter: 4–11 mm
4 (Optional) Power grid
scheduling signal
cable
Five-core outdoor
cable
● Conductor cross-
sectional area: 0.2–
1 mm
2
● Cable outer
diameter: 4–11 mm
5 AC output power
cable
a
Outdoor copper cable ● Conductor cross-
sectional area: 4–6
mm
2
● Cable outer
diameter: 10–21
mm
6 PE cable Single-core outdoor
copper cable
Conductor cross-
sectional area ≥ 4
mm
2
Note a: The minimum cable diameter depends on the fuse rating on the AC
side.
NO TE
● The minimum cable diameter should comply with the local cable standard.
● Factors inuencing cable selection are as follows: nominal AC current, type of cable,
routing method, ambient temperature, and maximum desired line losses.
SUN2000-(3KTL-10KTL)-M0
User Manual 5 Electrical Connections
Issue 06 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 33

Huawei SUN2000 M0 Series Specifications

General

Rated AC Output Power	3000W
European Efficiency	96.7%/97%/97%/97.3%/97.5%/97.8%
Communication	RS485, Wi-Fi
Protection Degree	IP65
Weight	17 kg
Dimensions	440 x 650 x 220 mm
Max. efficiency	98.6%
MPPT voltage range	200-1000V
No. of MPPTs	2
Operating temperature range	-25°C to +60°C
Cooling method	Natural convection
Protection rating	IP65
AC output voltage	230V
