Huawei SUN2000 M0 Series User Manual

NO TE
If FusionSolar app can access the network, you can access Device commissioning after
login to FusionSolar app.
Step 2 Connect to the inverter WLAN. Log in as installer, and perform Quick settings.
NO TE
● When the inverter is directly connected to the mobile phone using the built-in antenna,
the distance between the inverter and mobile phone must be less than 5 m without
obstructions in between to ensure the communication quality between the FusionSolar
app and inverter. The distance is for reference only and may vary depending on mobile
phones and whether there are obstructions between the inverter and the mobile phone.
● When connecting the SUN2000L to the FusionSolar app over a router, ensure that the
mobile phone and inverter are in the WiFi coverage of the router and the SUN2000L is
connected to the router.
● The router supports WiFi (IEEE 802.11 b/g/n, 2.4 GHz) and the WiFi signal reaches the
inverter.
● The WPA, WPA2, or WPA/WPA2 encryption mode is recommended for routers.
Enterprise-level encryption is not supported (for example, public hotspots requiring
authentication such as airport WiFi). WEP and WPA TKIP are not recommended because
these two encryption modes have serious security defects. If the inverter cannot be
connected using WEP, log in to the router and change the encryption mode to WPA2 or
WPA/WPA2. If the inverter cannot be connected using WEP, log in to the router and
change the encryption mode to WPA2 or WPA/WPA2.
SUN2000-(3KTL-10KTL)-M0
User Manual 6 Commissioning
Issue 06 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 65

Huawei SUN2000 M0 Series Specifications

General

Rated AC Output Power	3000W
European Efficiency	96.7%/97%/97%/97.3%/97.5%/97.8%
Communication	RS485, Wi-Fi
Protection Degree	IP65
Weight	17 kg
Dimensions	440 x 650 x 220 mm
Max. efficiency	98.6%
MPPT voltage range	200-1000V
No. of MPPTs	2
Operating temperature range	-25°C to +60°C
Cooling method	Natural convection
Protection rating	IP65
AC output voltage	230V
