Figure 4-16 Mounting a SUN2000L
Step 3 Tighten screw assemblies.
Fixing holes can be used in three combinations. Select a hole combination based on site
requirements. Combination A is preferred.
Figure 4-17 Fixing holes
Combination A: holes 2 and 3
Combination B: holes 1 and 3
Combination C: holes 1 and 4
Combination D: holes 2 and 4
