SUN2000L-(2KTL-5KTL)
User Manual
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 4-18 Tightening screw assemblies
Step 4 (Optional) Install an anti-theft lock.
The function of an anti-theft lock is to secure the SUN2000L to the mounting bracket and
protect it from stealing.
Prepare an anti-theft lock suitable for the lock hole diameter (Ф8 mm) by yourself.
Keep the key to the anti-theft lock safe.
Figure 4-19 Installing an anti-theft lock
