18
Operational descriptions for a Scenario: Outdoor Scenerios
Photocell ON/OFF
Automatic photocell ON/OFF control of outdoor lighting
Photocell ON/Sched OFF
Automatic photocell control ON and schedule control OFF of outdoor lighting
Photo ON/Sch OFF/Ovride SW
Automatic photocell control ON and schedule control OFF of outdoor lighting with
manual switch bypass TIMED-ON control.
Astro-Clock ON/OFF
Automatic ON/OFF control of outdoor lighting based on astronomic calculated
sunset and sunrise times for input longitude and latitude.
Astro-clock ON/Sched OFF
Automatic control ON based on astronomic calculated sunset time for input
longitude and latitude, and schedule control OFF of outdoor lighting.
Astro ON/Sch OFF/Ovride SW
Automatic control ON based on astronomic calculated sunset time for input
longitude and latitude, and schedule control OFF of outdoor lighting with manual
switch bypass TIMED-ON control.
Operational descriptions for a Scenario: Indoor Scenerios
Switch ON/OFF
Manual switch ON/OFF control.
Motion Sensor ON/OFF
Automatic motion sensor ON/OFF control.
Switch ON/Auto Motion OFF
Manual switch turns lights ON/OFF; motion sensor automatically turns lights OFF.
Lights turn ON only if switch is turned ON first.
Sched ON/OFF/Photo ON/OFF
Sched ON/OFF with photocell ON/OFF for daylight harvesting during schedule ON
hours.
Sch ON/OFF/Ph ON/OFF OvrSW
Schedule ON/OFF with photocell ON/OFF for daylight harvesting during schedule
ON hours and a temporary override TIMED-ON switch.
Motion ON/OFF/Photo OFF
Automatic control of lighting by a motion sensor, with daylight harvesting OFF while
occupants are present.
Switch ON/OFF/Photo OFF
Manual switch turns lights ON/OFF; daylight harvesting only operates while switch
is in the ON state.
Switch ON/Motion-Photo OFF
Manual switch turns lights ON/OFF; motion sensor and daylight-harvesting
photocell will automatically turns lights OFF. Lights turn ON only if switch is turned
ON first.
Schedule ON/OFF
Schedule ON/OFF control
Sched ON/OFF/Override SW
Schedule ON/OFF control and a temporary override TIMED-ON switch. Switch
allows for cancellation of impending schedule OFF event.
Sched ON/OFF/Blink Ovr SW
Schedule ON/OFF control with blink warning and manual override switch to extend
schedule OFF event to a later time.
Sched OFF/Blink Ovr SW
Schedule OFF control with blink warning and manual override switch to extend
schedule OFF event to a later time.
Sched ON/OFF/Blnk LineV SW
Schedule ON/OFF control, blink warning, LineV switch ON/OFF
Sched OFF/Blink LineV Sw
Schedule OFF control, blink warning, LineV switch ON/OFF.
Sched/Switch ON/OFF After hrs
Schedule ON/OFF control, with manual switch ON/OFF that is active only during
schedule OFF period.
Sch/Motion ON/OFF After hrs
Schedule ON/OFF control, with motion sensor ON/OFF that is active only during
schedule OFF period.
Master Override Switch
Master control override assigned to a switch to turn ON lights as an override to
other programmed controls.
Master Override Ext Input
Master control override assigned to an external input to turn ON lights as an
override to other programmed controls.
