Section 1
Installing and Removing Cargo
Tie-Downs
The rails are notched at each end
which allows the tie-downs to be
removed and placed on another
rail.
To remove a cargo tie-down,
retract the locator pin and slide the
tie-down along the rail to the
notch at the end of the rail.
Pull back to remove the tie-down.
To install a cargo tie-down, insert
the tie down at the notch on the
end of the rail.
Retract the locator pin and slide
the tie-down to the desired posi-
tion.
See the following, earlier in this
section, for more information:
• Adjusting Cargo Tie-Downs
When installing or removing a tie-
down from the front rail, slide the
corner cap toward the center of
the pickup bed to expose the
notches in the rail.
Remove the corner cap by pulling
the edge away from the rail.
Cargo Management System
Removal
To remove the cargo management
system, loosen the toggle bolts on
each rail until the rails can be
removed from the bed of the
truck.
Reverse the procedure to reinstall.
When reinstalling the rails,
tighten the toggle bolts to 17 Nm
(12.5 ft-lbs).
