130
Radar Overview
RADAR OVERVIEW
T
he radar scanner must be connected to the control head to enable radar features. Some of the features also require a
c
ompass/heading sensor.
Some of the instructions in the following sections vary depending on the connected radar model. Refer to the instructions for your
radar model as follows:
• Humminbird CHIRP Radar
• Humminbird Radar: RH 44, RH 45, AS 12RD2KW, and AS 21RD4KW
NOTE: To configure the Humminbird radar after installation or equipment repair, see Installation Information: Configure
Humminbird Radar. Humminbird CHIRP radar does not require configuration.
distance and bearing to cursor position
Radar View with Cursor Active
OR
Open the Cursor Menu
Move the Joystick to
Activate the Cursor
Tap to Activate the Cursor
orientation menuRadar X-Press Menu exit cursor
sensor status icons
cursor position
cursor
