OPERATION
11
STEP 3 — Attach the Bracket
Drill the pilot hole using a
3
∕
32
" drill bit and attach the
bracket using the screw provided.
IMPORTANT: Do not over torque the screw.
STEP 4 — Install the Bracket Cover
Slide the bracket cover over the magnetic hold-down bracket and mark the screw hole.
Remove the bracket cover once the screw hole is marked.
Drill the pilot hole using a
3
∕
32
" drill bit
and slide the bracket cover back over the
magnetic hold-down bracket.
Attach the cover using the screw provided.
IMPORTANT: Do not over tighten the screw.
STEP 5 — Place and Attach Second Bracket
Repeat steps 1 through 4 to install the second magnetic
hold-down bracket.
IMPORTANT: Make sure the bottom rail is level when
marking the second bracket location.
STEP 6 — Final Adjustments
Verify that the bottom rail is level.
