INSTALLATION
5
Mount the Installation Brackets — Outside Mount
Center the headrail over the window opening at the desired height. Use a pencil to lightly
mark each end of the headrail on the mounting surface.
Alternatively, measure the width of the headrail and use that width to mark the
headrail end points over the window opening.
Mark 2" from each end of the headrail.
If more than two installation brackets came with your order, space additional bracket(s)
evenly between the two end brackets and mark their location. Mount into wood
whenever possible.
Center the installation brackets on your marks and mark the location of the screw holes.
A minimum mounting surface height of 1
1
⁄
4
" for installation brackets or extension
brackets is required.
The top of the installation brackets or extension brackets should be at the desired
height. The brackets should be level and aligned.
When using extension brackets, mark two screw holes per bracket.
CAUTION: The rear of the brackets must be flush against a flat mounting surface. Do
not mount brackets on curved molding.
Drill the screw holes using a
3
⁄
32
" drill bit.
CAUTION: Use drywall anchors when mounting into drywall.
Window Opening
2" Space Evenly Space Evenly
2"
