Hunter Douglas Vignette Installation

INSTALLATION
6
Mount the Installation Brackets — Inside Mount
■ Measure and mark 3" in from each jamb (two bracket widths) for bracket location.
➤ If more than two installation brackets came with your order, space additional bracket(s)
evenly between the two end brackets. Mount into wood whenever possible.
Recommended Best Practice: To enhance ease of installation, position the front edge of the
installation bracket approximately
1
/ 4 " into the room.
■ Two-On-One Headrail Shades. Place the installation brackets as shown in the
illustration below.
■ Center the brackets on your marks and mark each of the screwholes.
➤ The minimum casement depth for installation
brackets is 1". Mark the rear set of installation
bracket holes with shallow mounting depths.
➤ The minimum casement depth for a fully
recessed mount is 4". Mark the front set of
bracket holes when depth permits.
IMPORTANT: The front edges of the installation
brackets must be level and aligned to eachother. For the best experience, mount the
brackets with the front lip outside the window casement.
■ Pre-drill the screw holes using a
3
/ 32 " drill bit.
CAUTION: Use drywall anchors when mounting
into drywall.
■ Use a level to check that the mounting surface is level.
Shim (not provided) the brackets if necessary.
■ Attach the installation brackets using the screws provided.
Proceed to “Install the Shade” on page9.
Jamb Jamb
Window Opening
Space Evenly
Space Evenly3" 3"
3"
Casement
Depth
3"
Casement
Depth
Jamb Jamb
Panel Split
Space Evenly
Space Evenly3"
3" 3" 3"

Hunter Douglas Vignette Specifications

General

Opacity Levels	room darkening
Control Options	Manual, Motorized
Energy Efficiency	Yes
UV Protection	Yes
Width	Custom
Height	Custom
Product Type	Roman Shades
Style	Modern, Traditional
Material	Fabric
Operation	Cordless
Customization	Yes
Light Control	Adjustable
Privacy	Adjustable
