AC Electric Systems
8.10
Connect and Turn on Shore Power above).
Switch on line 1 AC Main toggle switch breaker on
the AC panel.
Switch on the Parallel toggle switch breaker on the
AC panel. (The toggle switch is managed by a
slide-bar stopper. This stopper will only allow source
power to be paralleled from either 1 shore power line
with 50 amps or from the generator.)
Switch on the forward Air Conditioner toggle switch
breaker at the AC Panel.
Switch on the aft Air Conditioner toggle switch break-
er at the AC Panel.
Switch on the Air Conditioner Relay toggle switch
breaker on the AC Panel.
8.3.4.5 Generator Power to Air Conditioner
The generator has sufficient resources to power the AC
system, including the air conditioner. To power the air
conditioning, complete the following:
Execute the Generator Start sequence discussed
previous.
Switch on the Generator toggle switch breaker on
the AC panel. (The toggle switch is managed by a
slide-bar stopper. This stopper will only allow source
power to be from shore power or the generator).
Switch on the Parallel toggle switch breaker on the
AC panel. (The toggle switch is managed by a
slide-bar stopper. This stopper will only allow source
power to be paralleled from either 1 shore power line
with 50 amps or from the generator.)
Switch on forward Air Conditioner toggle switch
breaker at the AC Panel.
Switch on the aft Air Conditioner toggle switch break-
er at the AC Panel.
Switch on the Air Conditioner Relay toggle switch
breaker on the AC Panel.
NOTE: When using the air conditioning systems with other
appliances power up the air conditioner first.
NOTE: Consult the air conditioner manufacturers’ OEM manual
for air conditioner operation, care and maintenance.
3.
4.
5.
6.
7.
1.
2.
3.
4.
5.
6.
Always make certain that the pick-up and discharge
valves for the Air Conditioning System are opened
before using. Failure to do so will cause permanent
damage to your compressor. Also, be certain that
the strainer is clean. See the Water Systems section
for details on cleaning the Strainers.
8.3.4.6 Air Conditioning System Operation
Once power is sourced to the air conditioning, one simply
turns on the units at the air conditioner remote panels and
sets the temperature (see Fig. 8.19 for details on ducting
and venting). Refer to the Water System chapter in this
manual and the manufacturer’s OEM manual for more
detailed information regarding its operation.
Important: Be sure to close the air conditioner seacock
when the air conditioner is not in use.
8.3.6 Spare Breaker Positions
The AC Panel has spare toggle switch breaker positions
available for the protection and control of future added
components.
