English-46
MAINTENANCE
Replacing the light bulbs
For information about the bulb type, see “Technical data”.
1. Unscrew the two screws holding the cover on the
power servo housing.
Lift up the cover and turn it around the steering
shaft.
2. Unscrew the two screws holding the lamp insert.
Lift out the lamp insert.
3. Disconnect the cables from the bulbs.
4. Lift out the bulbs from the insert.
5. Insert the new bulbs. Make sure you use your
thumb to support the front.
6. Refit the cables, lamp insert and the cover on the
power servo housing.
8009-511
8009-512
8009-513
8009-522
