English-54
MAINTENANCE
9. Unhook the height adjustment strut (E) by moving
the rear part upwards:
Unload the strut if necessary by pulling the frame’s
forward section up or down.
10. Pull the handle (D) and unit simultaneously.
Release the handle when the unit has come
out a bit.
11. Pull out the unit so that it catches on the outer
hooks.
12. Lower the unit with the lifting lever on the driver’s
right side.
13. Pull the handle (D) so that the safety catch locks.
Check that the catch (A) is in the inset position.
14. Remove the unit from the machine.
8009-169
8009-170
8009-024
8009-171
