HUST CNC H6D-B3 MANUAL
27
Machine Illustration
Fig 34
Bending switch
Oil - System
Oil-Stop（output）
D-axis（Y）
SEVRO
L-axis（X）
SEVRO
-I001 I008 +I000
I006
I007
material
I009
+I002
-I003
I009
-I003
+I002
D-TYPE
O-TYPE
SEVRO
+I017
-I018
I010
R-axis（Z）
