Installation and Maintenance Manual
23
Smart Touch Controller Installer Menu Functions
The Installer Menu can be accessed only by entering the User Menu first, and then by pressing the
Reset button and the Open button simultaneously.
To restore the factory default settings, go to menu item [Fd_0] and change the setting to 1,
then press the Program Menu button. The entire menu will reset to the factory defaults.
Installer Menu Options Default Description
I
1 [uC 0] Set UL Usage Class 0 0 = gate disabled, Set Class 1 through 4 use
I
2 [Sh 0] Set Handing of gate 0 0 = gate disabled, r = Right Hand, L = Left Hand
I3 [Fd 0] Load Factory Defaults 0 0 = User settings, 1 = Load defaults (resets full menu)
I4 [dg 0] Set Master/Slave type 0 0 = solo operator, 1 = Slave unit, 2 = Master unit
I
5 [Ch 0] Set AC Charger or Solar 0 0 = DC + AC charger 1 = DC + Solar charger
I6 [Fo 0] Enable Fire Dept. Open 0 0 = disabled, 1 = enabled
I7 [oC 0] Enable Emergency close 0 0 = disabled, 1 = enabled
I8 [SE 3] Inherent Sensor sens. 3 1 = maximum sensitivity, 9 = Lowest sensitivity
I
9 [SS 0] Inherent Sensor function 0 1 = stop only (note, functions in usage class 4 only)
I
10 [LC 0] Leaf delay Close 0 0 = none (1-7) 1/2 second steps (Master/Slave only)
I
11 [Lo 0] Leaf delay Open 0 0 = none (1-7) 1/2 second steps (Master/Slave only)
I12 [rt 0] Maximum run timer 0 0 = 60 Seconds max run, 1 = 300 Seconds max run
I13 [Po 0] Partial Open distance 0 0 = none, or 7 - 99 seconds
I14 [EC 0] PEC reverse to open 0 0 = Close eye stops only, 1 = 2 sec reverse to open
I15 [EO 0] PEO reverse to close 0 0 = Open eye stops only, 1 = 2 sec reverse to close
I16 [gr 0] Edge reverse to open 0 0 = Edge reverses fully open, 1 = 2 sec reversal only
I17 [Sr 1] IES reverse to open 1 0 = IES reverses fully open, 1 = 2 sec reversal only
I18 [PC 0] Set PEO/ PEC - NO/NC 0 0 = Normally Open PE output, 1 = N.C. (supervised)
I19 [gC 0] Set Edge input - NO/NC 0 0 = Normally Open Edge output, 1 = Normally Closed
I20 [tC 1] Time clock/ Interlock input 1 0 = select Time Clock, 1 = select Open Interlock
I21 [or 1] OOLD detector function 1 0 = pause closing only, 1 = enable reversing to open
I22 [ir 1] IOLD detector function 1 0 = pause closing only, 1 = enable reversing to open
I23 [dL 1] Vehicle detector logic 1 1 = std, 2 & 3 = quick close, 4 = full anti-tailgate*
I24 [r1 0] User relay 1 option 1 0 = disabled, 1 - 19 = see output options page 28
I25 [r2 0] User relay 2 option 6 0 = disabled, 1 - 19 = see output options page 28
I26 [r3 0] User relay 3 option 1 0 = disabled, 1 - 19 = see output options page 28
I
27 [t L 0] Gate Open alert 2 0 = 0 sec, 1=15s, 2=45s, 3=75s, 4=105s, 5=135s
I
28 [Lt 0] Loitering alert 3 0 = 0 sec, 1=15s, 2=45s, 3=75s, 4=105s, 5=135s
I29 [ELd0] Test factory ELD* 0 0=Run, 1=show freq, 2=show call level 0-7, 3= set Freq 1-4
I30 [iLd0] Test factory IOLD* 0 0=Run, 1=show freq, 2=show call level 0-7, 3= set Freq 1-4
I31 [oLd0] Test factory OOLD* 0 0=Run, 1=show freq, 2=show call level 0-7, 3= set Freq 1-4
I32 [SLd0] Test factory SLD* 0 0=Run, 1=show freq, 2=show call level 0-7, 3= set Freq 1-4
*See page 43 for description of vehicle detector & Loop Fault diagnostics
These Notes Refer to the Menu Above:
I
1,
I
2 These settings must be configured or the gate cannot function and menu will not exit.
I
5 These settings appear only if the factory has provided a DC powered gate operator
I9
IES stop only setting [SS __] does not appear unless set as a class 4 operator
I
10,
I
11 These settings appear only if the Installer Menu is set for Master / Slave function
I
27,
I
28 These settings appear only if the Installer Menu has set relays r1-r3 for these alerts
