Use and maintenance manual S20DSP
" Ensure that the head lowering control is at zero (fully closed);
" start the belt turning by pressing “CYCLE START”;
" if all the above operations have been carried out correctly, the blade motor
will start up and the blade will start rotating.
Ensure that the blade moves in the correct direction as shown in the
above figure. If it does not, simply reverse two of the phase wires on the
machine power supply input.
The sawing machine is now ready to start the work for which it was designed.
Chapter 5 provides a detailed description of the various functions of the machine
and its operating cycles.
