HYDACELECTRONIC ENS 3000 User Manual

ENS 3000 Page16
Status 21.08.2015 HYDAC ELECTRONIC GMBH Part No. 669850
8.5 SETTING RANGES FOR THE WINDOW FUNCTION
Probe length
in inch *
Lower switch value
in inch *
Upper switch value
in inch *
9.80 0.10 .. 6.55 0.20 .. 6.60
16.20 0.20 .. 11.15 0.30 .. 11.25
20.50 0.25 . 15.05 0.35 .. 15.15
28.70 0.40 .. 22.80 0.60 .. 23.00
The increment for all units is 0.05 inch
Probe length
in cm
Lower switch value
in cm *
Upper switch value
in cm*
25.0 0.3 .. 16.7 0.4.. 16.8
41.0 0.5 .. 28.4 0.7 .. 28.7
52.0 0.6 . 38.3 0.9 .. 38.6
73.0 0.9 .. 57.9 1.4 .. 58.4
The increment for all units is 0.1 cm.
8.6 SETTING RANGES FOR THE OFFSET
Probe length
in inch
Measuring range
in inch
Setting range for
Offset in inch*
9.8 6.7 0 .. 26.8
16.2 11.4 0 .. 45.6
20.5 15.35 0 .. 61.4
28.7 23.2 0 .. 69.6
The increment for all units is 0.05 inch.
Probe length
in cm
Measuring range
in cm
Setting range for
Offset in cm *
25 17 0 .. 68
41 29 0 .. 116
52 39 0 .. 156
73 59 0 .. 177
The increment for all units is 0.1 cm.
* All ranges given in the table can be adjusted by the increments shown
