ENS 3000 Page26
Status 21.08.2015 HYDAC ELECTRONIC GMBH Part No. 669850
13 Pin assignment
13.1 PIN CONNECTIONS WITH 1 OR
2 SWITCHING OUTPUTS
13.2 PIN CONNECTIONS
WITH 4 SWITCHING OUTPUTS
Model with 4 switching outputs and 2
analogue outputs
Connector 8 pole M12x1
Imax. 250 mA
SP 1
18 .. 35 V
+
-
U=0..10V
Analog
Temp.
R
L
1
3
8
4
ENS 3X1P-8
U=0..10V
Analog Niv.
7
Imax. 250 mA
SP 2
2
Imax. 250 mA
SP 3
5
Imax. 250 mA
SP 4
R
L
6
Model with 2 switching outputs
and 1 analogue outputs
Connector 5 pole M12x1
Model with 1 switching output
and 1 analogue outputs
Connector 4 pole M12x1
Model with 2 switching outputs
Connector 4 pole M12x1
