HYDACELECTRONIC ENS 3000 - For Use with Ouput Options 2, 3 and 5

To Next Page

To Previous Page

ENS 3000 Page31

Status 21.08.2015 HYDAC ELECTRONIC GMBH Part No. 669850

16.1.2 For use with ouput options "2", "3" and "5"

ZBE 08 (5 pole)

Female connector M12x1, right-

angle

Part No.: 6006786

ZBE 08-02 (5 pole)

Female connector M12x1, right-

angle with 2m (78.7 inch) cable,

Part No.: 6006792

ZBE 08-05 (5 pole)

Female connector M12x1, right-

angle with 5m (197 inch) cable

Part No.: 6006791

Colour code: Pin 1: brown

Pin 2: white

Pin 3: blue

Pin 4: black

Pin 5: grey

ZBE 08S-02 (5-pole)

Female connector M12x1, right-

angle with 2m (78.7 inch) cable,

screened

Part No.: 6019455

ZBE 08S-05 (5-pole)

Female connector M12x1, right-

angle with 5m (197 inch) cable,

screened

Part No.: 6019456

ZBE 08S-10 (5-pole)

Female connector M12x1, right-

angle with 10m (394 inch) cable,

screened

Part No.: 6023102

Colour code: Pin 1: brown

Pin 2: white

Pin 3: blue

Pin 4: black

Pin 5: grey
