Page #28 background image
ENS 3000 Page28
Status 21.08.2015 HYDAC ELECTRONIC GMBH Part No. 669850
Other data
Max. tank pressure 7 psi (short-term 40 psi t < 1 min)
supply voltage
when applied according to UL specifications
9 .. 35 V DC without analogue output
18 .. 35 V DC with analogue output
- limited energy –
according to
9.3 UL 61010; Class 2;
UL 1310 / 1585; LPS UL 60950
Current consumption max. 2,470 A total
max. 90 mA inactive
switching outputs and
2 analogue outputs
Residual ripple of supply voltage
5 %
Fluids Hydraulic oils (mineral based), synth. oils,
fluids containing water ***
Parts in contact with fluid Ceramic
Display 4-digit, LED, 7 segment, red,
height of digits 7 mm
Weight 180 .. 300 g, according to probe length
Note: Reverse polarity protection of the supply voltage, excess voltage, override and short circuit
protection are provided.
FS (full scale) = regarding the complete measuring range
* specifies (at constant level)
** environmental conditions according to 1.4.2 UL 61010-1; C22.2 No. 61010-1
*** further fluids on request
