Hydrafeed MSV 80 - Page 112

109
4. System Setup
( 14 ) The setting for speed of torque value to " 0 "
You can set speed value
speed setting ranges: 5 – 99 ( 0.26 -5.2 kg / 0.1 sec )
Factory setting Bar diameter < 13 mm value : 15 ( 0.8 kg / 0.1 sec)
Factory setting Bar diameter >= 13 mm value : 50 ( 2.6 kg / 0.1 sec)
Factory setting Chuck close bar check value : 10 ( 0.52 kg / 0.1 sec)
