9.1 Input List
Code Description
X0 Servo encoder A pulse
X1 Servo encoder B pulse
X2 Loading bar encoder A pulse
X3 Loading bar encoder B pulse
X4 Bar length measuring sensor (LS-4)
X5 Servo in position DO1(INP)
X6
X7
X8 Servo alarm DO6(ALM)
X9 Servo zero speed DO2(ZSP)
XA Auto / Manual (S1)
XB Bar feeder E.M.G stop (S2)
XC Reference switch (LS-1)
XD Loading up limit switch (LS-2)
XE Loading down limit switch (LS-3)
XF Cover interlock (S4)
X300 Sliding rail interlock (S3)
X302 Foot switch (S5)
X303 Chuck open signal
X304 CNC M code signal (Feed command)
X305 CNC Auto mode signal
X306 CNC Emergency stop signal
X307 CNC M code signal (Loading new bar command)
