32
3. User Setup
3.4.3 Pushrod retract Position
(1) Retract length
Select 3.
< pushrod retract position>
Two retract positions to be set
(1) Retract length
(2) Fixed retract position
- Touch on A: numeric.
- Seems a numerical display.
- Write A length and press <ENT>.
- retract length (A) :
During operation of CNC, to avoid the
damage of pushrod with the direct
contact to the bar.
Note: min setting: 10 mm
To Next Page
