4. System Setup
4.13 Chuck type Selection
Select 12.< Chuck type selection >
Chuck type selection : In order to feed
correct chuck open signal to bar feeder,
you may alter the signal by selecting
normal or revese chuck .
1. Chuck open
2. PLC I/O input signal X303 ON
1. Chuck close
2. PLC I/O input signal X303 ON
Note: To check X303, please refer “6. PLC INPUT / OUTPUT SINGNAL”
