Hydrafeed MSV 80 - Spare Parts List

150
9. Appendix : Electronic Controller
9.3 Spare Parts List
NO Name Description of goods Placement
E001
E002
E003 32.1 Servo motor encoder cable /32.4:E
E004 32.2 Servo motor power cable /32.6:E
E005 33.1 Servo controller cable /33.1:C
E006 33.2 Servo controller cable /33.5:C
E007 50.1 Programming cable /50.3:E
E008 AD Inverter /43.0:C
E009 AENC Loading mechanism encoder /10.8:C
E010 DA2 Torque/Speed Module /33.4:E
E011 EIB Encoder interfacing board /33.1:E
E012 F4 Fuse t/b with LED DC24V /1.4:F
E013 FTR1 Noise filter /1.4:A
E014 LS1 Proximity switch /11.5:B
E015 LS2 Proximity switch /11.6:B
E016 LS3 Proximity switch /11.7:B
E017 LS4 Thur-beam sensor
/10.4:B
/10.5:B
E018 M2 3-Phase AC motor with brake /43.5:A
E019 M2 Gear box Gear box
E020 MSA Power relay + auxiliary contact
/1.6:A
/5.2;B
/5.5:E
/5.6:C
E021 MSB Power relay + auxiliary contact
/1.8:A
/5.5:D
/5.8:E
/12.7:B
E022 PCB1 PC Board set
E023 PLC1 Programmable controller
/1.7:E
/10.0:E
/11.0:E
/12.0:E
/20.0:A
/21.1:A
/50.1:D
E024 PLC2 Programmable controller
/12.1:E
/21.4:A
/22.1:A
